Delta Power supply พาวเวอร์ซัพพลาย รุ่น PMT-24V100W2BA

Panel Mount

PMT2 Series

PMT-24V100W2BA

Output Voltage

24V

Output Power

108W

Output Current

4.5A

Input Voltage Range

90-264Vac

Dimensions (L x W x H)

129 x 97 x 30 mm

5.08” x 3.82” x 1.18”

Unit Weight

0.285 kg (0.63 lb)

Highlights & Features

● Household appliance approvals according to IEC/EN 60335-1, IEC/EN 61558-1 and IEC/EN 61558-2-16

● Universal AC input voltage range

● No load power consumption < 0.3W

● Low profile design : 30mm height

● OVC III, Pollution Degree 3

● Wide operating temp -30°C ~ 70°C (Support -40°C cold start)

● Conforms to harmonic current IEC/EN 61000-3-2, Class A

● High MTBF > 700,000 hrs per Telcordia SR-332

● Compliance with SEMI-F47
